Fire Magic Custom I Gourmet Charcoal 22-SC01C Parts Diagram

Post-Mount Tap a red dot or pick from the parts list.

Parts diagram

Fire Magic Custom I Gourmet Charcoal 22-SC01C exploded parts diagram showing 9 replacement parts

About the Fire Magic Custom I Gourmet Charcoal 22-SC01C parts

This is the exploded parts diagram for the Fire Magic Custom I Gourmet Charcoal 22-SC01C post-mount grill. It shows 9 replacement parts, and 9 of them can be ordered online today. Tap a red dot or pick a part from the list to see its Fire Magic part number. Parts change over the years, so if your grill looks a little different, text us a photo and we’ll confirm the fit.

Other Charcoal diagrams

Firemaster 30-inch Charcoal CountertopFiremaster 23-inch Charcoal CountertopLift-A-Fire 30-inch Charcoal Built-InLift-A-Fire 23-inch Charcoal Built-In

Not sure which model you have?

On most Fire Magic grills the model name is on the grill head or the control panel, and it’s also printed in your owner’s manual. The serial number tag is under the drip tray, inside the left door on cart grills, or behind the control panel. Send us a photo and we’ll tell you exactly what you have.
